Omcan USA 50069 Back Bar Coolers
Omcan BD-CN-0032-HC Draft Beer Cooler / Kegerator – 90"
5 Half-Barrel Capacity • Two Dispensing Towers • 32 cu. ft.Pour perfect pints shift after shift. The Omcan BD-CN-0032-HC combines a roomy 32 cu. ft. interior with dual draft towers and energy-saving R290 refrigeration, giving bars, breweries and event venues everything they need to keep up to five full-size kegs ice-cold and ready to serve.
Why You’ll Love It
- Holds up to 5 ½-barrel kegs or a custom mix of kegs & cans on six adjustable PVC-coated shelves.
- (2) factory-installed draft towers with faucets let you feature multiple beers or house brews at once.
- 33 – 41 °F / 0.5 – 5 °C temperature range controlled by a simple mechanical thermostat and verified with an internal thermometer.
- Eco-friendly R290 hydrocarbon refrigerant + ¼ HP compressor = quick pull-down, lower energy costs and a reduced carbon footprint.
- Three self-closing solid doors with integrated locks prevent heat infiltration and protect your inventory.
- All-stainless steel contact surfaces (countertop, interior walls & floor) wipe clean fast and never impart off-flavours.
- LED interior lighting shows stock levels at a glance without warming the cabinet.
- Heavy-duty black vinyl-clad steel exterior resists dents, scratches and everyday bar abuse.
- Removable installation board provides tool-free access to the condenser for routine cleaning.
- cETLus, ETL-Sanitation & NSF certified for worry-free commercial compliance across North America.
At-a-Glance Specs
| Model / Item | BD-CN-0032-HC / 50069 |
|---|---|
| Exterior Dimensions (W×D×H) | 90.4" × 27.7" × 48.4" (2295 × 704 × 1229 mm) |
| Interior Capacity | 32 cu. ft. (≈906 L) — 5 × ½-bbl kegs |
| Doors / Sections | 3 solid, self-closing doors with locks |
| Dispensing Towers | (2) single-column chrome towers, pre-piped & insulated |
| Shelving | (6) height-adjustable PVC-coated wire shelves |
| Temperature Range | 33 °F – 41 °F (0.5 °C – 5 °C) |
| Refrigerant | R290 (hydrocarbon) |
| Compressor | ¼ HP, side-mounted |
| Electrical | 110 V / 60 Hz / 1-Ph, 4.7 A, NEMA 5-15P cord |
| Net / Shipping Weight | 374 lb (170 kg) / ships on pallet |
| Certifications | cETLus • ETL-Sanitation • NSF |
| Warranty | 2 Years Parts & Labour / 5 Years Compressor |
Looking for more taps? Ask us about the optional Omcan double-tap tower (#44224).
